[Phyloseq] phyloseq을 이용해 phylum별로, sample type별로 NMDS plot그리기

1. 데이터 다운로드

- 예제 데이터 : https://mibwurrepo.github.io/Microbial-bioinformatics-introductory-course-Material-2018/introduction.html

- 링크 : https://github.com/mibwurrepo/Microbial-bioinformatics-introductory-course-Material-2018

- 다운 방법 : 링크 접속 -> code -> Download ZIP

- 분석 환경 세팅

1. Download ZIP클릭
2. [the Microbial-bioinformatics-introductory-course-Material-2018-master.zip] 폴더 압축 풀기
3. [input_data] 압축 풀기
4. [humanmicrobiome.zip] 압축 풀기 -> 폴더 안에 있는 "humanmicrobiome.biom"를 [input_data] 폴더로 옮기기
5. "microbiometutorials.Rproj" 파일 클릭 -> 현재 위치를 기본 위치로 설정해 준다



2. 데이터 살펴보기

ps <- readRDS("./phyobjects/ps.ng.tax.rds")
# phyloseq-class experiment-level object
# otu_table()   OTU Table:         [ 4710 taxa and 474 samples ]
# sample_data() Sample Data:       [ 474 samples by 30 sample variables ]
# tax_table()   Taxonomy Table:    [ 4710 taxa by 6 taxonomic ranks ]
# phy_tree()    Phylogenetic Tree: [ 4710 tips and 4709 internal nodes ]

474개의 샘플과 그 샘플에 관한 30가지의 데이터와 6개의 랭크를 가진 계통수를 포함하고 있다

phyloseq데이터를 만드는 방법은 원문의 4.4 Making a phyloseq object를 참고 바람

otu_table(ps)[1, ]

왼쪽의 raw name이 OTU ID 이름이고 column name이 sample이다



3. 패키지 다운로드 및 phyloseq 파일 import

# import phyloseq
ps <- readRDS("./phyobjects/ps.ng.tax.rds")

# 데이터가 너무 크니가 크기를 줄이자
ps_rs = prune_taxa(taxa_sums(ps) > 100, ps)
ps_prop <- transform_sample_counts(ps_rs, function(x) 100*x/sum(x))  #상대도수로 바꾼다



4. Sample별로 NMDS 분석 plot그리기

이제 원하는 분석을 해준다

otu <- otu_table(ps_prop)
ord <- ordinate(physeq = ps_prop,
                method = "NMDS", #  Default is "DCA" or "CCA", "RDA", "CAP", "DPCoA", "NMDS", "MDS", "PCoA"
                distance = "bray") # Default is "bray" or "unifrac", "wunifrac", "jaccard",
p <- plot_ordination(ps_prop, ord, "samples", color="sample_type")
p



5. ggplot으로 그리기

samples <- data.frame(scores(ord$points))
samples$SampleType<- get_variable(ps_prop, "sample_type") # sampledata에 "sample_type"이라는 열을 가져와서 열 추가

samples
#                                          MDS1        MDS2 SkinType
#1927.SRS014341.SRX020546.SRR043648 -0.81474818  0.16662040  Vaginal
#1927.SRS014837.SRX020546.SRR043659 -1.05460391 -0.33291868  Vaginal
#1927.SRS015389.SRX020546.SRR043661  0.57928105 -0.05124357    Stool
#1927.SRS014627.SRX020546.SRR043662 -0.92117159 -0.28196423  Vaginal
#1927.SRS014923.SRX020546.SRR043675  0.47449253 -0.16889302    Stool
#1927.SRS015127.SRX020546.SRR043678 -0.05396112  0.34111887     Oral

library(ggplot2)
p <- ggplot(samples) +
  geom_point(aes(x = MDS1, y = MDS2, color=SampleType))
p

같은 그림이 나온다



stat_ellipse()를 사용해 원으로 묶어 주자

ggplot(samples)+ #sets up the plot. brackets around the entire thing to make it draw automatically
  geom_point(aes(x = MDS1, y = MDS2, color=SampleType)) + #puts the site points in from the ordination, shape determined by site, size refers to size of point
  stat_ellipse(level = 0.9, aes(x = MDS1, y = MDS2, fill=SampleType),geom = "polygon", alpha = 0.3)+
  theme_bw()+
  theme(legend.position = "none")





6. phylum 별로 NMDS 분석 plot그리기

spps <- as.data.frame(scores(ord, choices=c(1,2),display=c("species")))
spps_species <- as.data.frame(tax_table(ps_prop))

head(spps_species)
#             Domain        Phylum       Class         Order         Family       Genus
#9410494158 Bacteria Bacteroidetes Bacteroidia Bacteroidales Prevotellaceae  Prevotella
#9410494576 Bacteria Bacteroidetes Bacteroidia Bacteroidales Prevotellaceae  Prevotella
#9410491420 Bacteria Bacteroidetes Bacteroidia Bacteroidales Bacteroidaceae Bacteroides
#9410491569 Bacteria Bacteroidetes Bacteroidia Bacteroidales Bacteroidaceae Bacteroides
#9410491595 Bacteria Bacteroidetes Bacteroidia Bacteroidales Bacteroidaceae Bacteroides
#9410491783 Bacteria Bacteroidetes Bacteroidia Bacteroidales Bacteroidaceae Bacteroides

spps$Phylum <- factor(spps_species$Phylum) # making a column with species names

head(spps)
#               NMDS1       NMDS2        Phylum
#9410491526 0.6314447 -0.08904021 Bacteroidetes
#9410491516 0.6231495 -0.10382150 Bacteroidetes
#9410492612 0.4698253 -0.37411464 Bacteroidetes
#9410491521 0.6435790 -0.04185019 Bacteroidetes
#9410491824 0.5839583 -0.02245883 Bacteroidetes
#9410491817 0.5585791 -0.16516024 Bacteroidetes

p <- ggplot()+
 		 geom_point(data=spps, aes(y=NMDS2, x=NMDS1, color=Phylum))
p



6. phylum + Sample type 별로 NMDS 분석 plot그리기

p <- ggplot(samples)+ #sets up the plot. brackets around the entire thing to make it draw automatically
  		geom_point(aes(x = MDS1, y = MDS2, shape=SampleType)) + #puts the site points in from the ordination, shape determined by site, size refers to size of point
  		geom_point(data=spps, aes(y=NMDS2, x=NMDS1, color=Phylum))
p







---

참고

https://github.com/joey711/phyloseq/issues/105
